CP-VNC-D51R3C-D , 5mp
₹ 1,888 / Piece
₹ 3,000
37%
CP-VNC-D51R3C-D
5 MP Full HD WDR Array Dome Camera - 30Mtr.
- 1/2.7” 5MP PS CMOS Image Sensor (6.858 centimeters)
- 5MP(2592 x 1944): Max. 20fps
- Ultra 265,H.265, H.264, MJPEG Triple-stream Encoding
- WDR(120dB), Day/Night(ICR), 2D/3D-DNR,Corridor mode, ROI,Digital defog, AWB, AGC, BLC, HLC
- 2.8mm lens (3.6mm optional)
- Array Range of 30 Mtrs, Smart IR, IP67, PoE
- Mobile Software: Android, iOS
- CMS Software: IVMS
Specification
| Image Sensor | 1/2.7” 5MP Progressive scan CMOS (6.858 centimeters) |
| Minimum Illumination | Colour: 0.005Lux (F1.6, AGC ON) 0 Lux with IR |
| BodyType | Dome |
| Shutter Speed | Auto/Manual, 1~1/100000 s |
| White Balance | Auto/Manual |
| Lens | 2.8mm (3.6mm Optional) |
| Gain Control (AGC) | Auto/Manual |
| Video Compression | Ultra 265,H.265, H.264, MJPEG |
| Angle of View | 105.75° / 86.9° |
| Back Light Comp. | BLC / HLC / WDR(120dB) |
| Frame Rate | Main Stream: 5MP: Max. 20fps, 4MP: Max. 30fps, 3MP: Max. 30fps, 2MP: Max. 30fps , Sub Stream: 2MP: Max. 30fps, Third Stream: D1: Max.30fps |
| Video Streaming | Triple |
| Resolution | 2592 x 1944 |
| Motion Detection | Up to 4 areas |
| OSD | Up to 8 OSDs |
| Privacy Mask | Up to 8 areas |
| ICR | IR-cut filter with auto switch (ICR) |
| ROI | Up to 8 areas |
| Audio | Built-in Mic |
| Protocol | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS , ONVIF (Profile S, Profile T), API |
| Ethernet | 10M/100M Base-TX Ethernet |
| IR Range | Array Range of 30 Mtr., Smart IR |
| Operating Temperature | -30°C ~ +60°C (-22°F ~ 140°F) |
| Humidity | <95% RH (non-condensing) |
| Power Source | 12 V DC±25%, PoE (IEEE802.3 af) |
| Power Consumption | Max. 5W |
| Weatherproof Standard | IP67 |
| Dimension | Φ126mm x 94mm (Ø5.0” x 3.7”) |
| Weight | 0.45kg |
